neff i95bbe2n0, n 50, island hood, 90 cm, stainless steel
bauform
- Island dining, 90 cm
- box Slimline
- For ceiling installation above cooking islands
- Energy efficiency class: b (on an energy efficiency class scale from a+++ to D)
- Average energy consumption: 74.3 kwh/year*
- Fan efficiency class: b*
- lighting efficiency class: A*
- Grease filter efficiency class: b*
- optional exhaust air or recirculation mode
- For recirculation operation a standard recirculation set or a Clean Air Plus recirculation set (optional accessory) is required
- Noise min./max. normal level: 45/57 db
- Noise values according to en 60704-2-13 in exhaust air mode:
- Max. normal level:57db(A) re 1 pw
- Intensive stage:68 db(A) re 1 pw
- Fan capacity in exhaust air mode according to en 61591:
- max. normal stage438 m³/h, intensive stage 754 m³/h
- when using the separately available Clean Air Plus recirculation set (optional accessory), your unit will achieve the following values in recirculation mode:
- Recirculation stage: Max. normal operation:390m³/h
- Intensive stage:527m³/h
- Noise level recirculation: Max. normal mode:67db(A) re 1 pw
- Intensive stage:73 db(A) re 1 pw
- Extremely quiet operation due to special noise insulation
- High, finely adjustable air output due to electronic control system
- 3 power levels and
- 1 intensive stage
- Intensive levels with automatic reset
- Uniform, bright illumination with 4 x 1.5 w LED module
- illuminance: 409 lux
- Color temperature: 3500 K
- Easy to clean Aerodynamically optimized inner frame
- Cassette with aluminum frame
- Metal grease filter, Dishwasher safe
- energy efficient condenser motor
- Unit dimensions exhaust air (hxwxd): 744-924 x 898 x 600 mm
- Unit dimensions recirculation (HxwxD): 744-1044 x 898 x 600 mm
- Unit dimensions recirculation with CleanAir Plus recirculation set (HxwxD): 812-1044 x 898 x 600 mm
- with backflow flap
- Double-flow high-performance fan
- Exhaust air spigot ø 150 mm (ø 120 mm enclosed)
- Total connected load: 256 w
- Length of connection cable: 1.3 m with plug
- Voltage: 220 - 240 V
| Energy efficiency class: | B |
| Colour: | Stainless steel |
| Product type: | Extractor bonnet |
| Installation type: | Island |
| device width: | 90 cm |
| controls: | Short-stroke keys SSD-??????? SSD-??????? LED |
| Shipping weight: | 39,00 kg |
| Item weight: | 28,00 kg |
| Dimensions ( Length × Width × Height ): | 60,00 × 89,80 × 4,60 cm |
- Product series: n 50
- Color devicestainless steel
- Basic color of the product: not applicable
- Housing color: stainless steel
- Material chimney: stainless steel
- Specify material of housing: stainless steel
- type of construction: island/ceiling ventilator
- Control: Electronic
- type of constructionbuilt-in
- Type of installationisland
- controls: Short-stroke keys, LED
- Decorable: not applicable
- Fan position: motor in the chimney
- Type of airflow: Convertible
- Connected load: 256 w
- Fuse protection: 10
- Voltage: 220-240 V
- Frequency: 50; 60 TPU00040
- Length connection cable: 130 cm
- Plug type: Schuko/Gardy.w.grounding
- Device width89,8 cm
- Device depth60 cm
- Packed unit height89 cm
- width of packed unit61 cm
- Depth packed product103 cm
- net weight: 28,8 kg
- gross weight: 39,2 kg
- Height chimney exhaust air max.92,4 cm
- Height chimney exhaust air min.: 74,4 cm
- Height chimney recirculation max.104,4 cm
- Height chimney recirculation min.74,4 cm
- Average annual energy consumption: 74.3 kwh/year
- Liquid dynamic efficiency (2010/30/EU): 26.3
- lighting efficiency (2010/30/EC)58.4 lux/watt
- Grease filter efficiency (2010/30/EU): 87.0 %
- Max. Air volume: 438 m³/h
- Minimum air flow: 260 m³/h
- Air flow amplified (2010/30/EU): 754 m³/h
- Loudness at max. speed (2010/30/EC)57 db
- Loudness at min. speed (2010/30/EC)45 db
- Volume amplified (2010/30/EC)68 db
- Energy consumption in standby mode (2010/30/EC): 0.19 w
- Sound power db: 57 db(A) re 1 pw
- Noise level with fast cooking position (booster): 68 db(A) re 1 pw
- Energy intelligent appliance, can optimize consumption behavior (2017/1369/EU): no
- Wireless communication possible: no
- network broadband technology: not applicable
- SIM card slot available: no
- Type of interface for control: no
- Remote upgrade possibility: no
- Possibility of remote update for maintenance: no
- Possibility of voice controlno
- Manual controls: Short-stroke keys
- Remote controlno
- Total blower power: 250 w
- Max. Fan capacity - exhaust air mode: 438 m³/h
- Max. fan power at intensive stage - exhaust air mode: 754 m³/h
- Max. Fan power - recirculation mode390 m³/h
- Max. fan power at intensive stage - recirculation mode: 527 m³/h
- lighting efficiency (2010/30/EC): On/Off
- Total light intensity: 409 lux
- Grease filter material: aluminum washable
- Diameter exhaust port: 12 cm
- Type of grease filtercassette
- Backflow flapyes
- Odor filter: no
- Type of lights used: LED
- COMbInED_nOMenCLATURE_CODE: 84146000
