- Energy efficiency class: d (on an energy efficiency class scale from a+++ to d)
- average energy consumption: 69.3 kWh/year*
- Fan efficiency class: E*
- Lighting efficiency class: E*
- Grease filter efficiency class: d*
- Noise min./max. normal level: 53/68 dB
- Under-cabinet hood, 60 cm
- For installation under a wall cabinet or on the wall
- Choice of exhaust or recirculation operation
- For recirculation operation, a standard activated carbon filter is required (optional accessory)
- Fleece filter
- fume hoods for 3 power levels
- Workplace lighting with 1 x LEd 4w E14
- Illuminance: 45 lux
- Color temperature: 3000 K
- Swiveling washer flap made of glass
- Exhaust air capacity according to en 61591:
- max.250 m³/h
- Noise values according to en 60704-3 and en 60704-2-13 max. normal level exhaust air operation: 68 dB(A) re 1 pW (54 dB(A) re 20 ?Pa sound pressure)
- Max. Flow rate: 250 m3/h
- Unit dimensions (HxWxD): 150 x 600 x 482 mm
- Exhaust air connection ø 120 mm, 100 mm
- Length of connection cable: 1.45 m with plug
- Total connected load: 119 W
- with backflow flap
Energy efficiency class: | D |
Colour: | Stainless steel |
Product type: | Extractor bonnet |
Installation type: | Sub-unit |
device width: | 60 cm |
controls: | Without Slide switch |
Shipping weight: | 10,00 kg |
Item weight: | 6,00 kg |
Dimensions ( Length × Width ): | 48,20 × 60,00 cm |
- Product series: n 30
- Color devicestainless steel
- Basic color of the product: not applicable
- Housing color: stainless steel
- Specify case material: stainless steel
- Construction type: Fan module/intermediate/undermount hood
- Control: Mechanical
- Design: Built-in
- Type of installation: Sub-assembly unit
- Controls: Without, slide switch
- decoratable: not applicable
- Fan position: motor in housing
- Type of air duct: Convertible
- Connected load: 119 W
- Voltage: 220-240 V
- Frequency50 TPU00040
- Length connection cable145 cm
- Plug type: Schuko/Gardy.w.grounding
- Device width60 cm
- Device depth: 48,2 cm
- Packed unit height26,7 cm
- Width packed unit65,2 cm
- Depth packed product74,8 cm
- net weight: 6,7 kg
- Gross weight: 10,7 kg
- Height chimney exhaust max.: 15 cm
- Height chimney exhaust air min.: 15 cm
- Height chimney recirculation max.15 cm
- Height chimney recirculation min.15 cm
- average annual energy consumption: 69.3 kWh/year
- Liquid dynamic efficiency (2010/30/EU): 8.1
- Lighting efficiency (2010/30/EC)11.0 lux/watt
- Grease filter efficiency (2010/30/EU): 65.1 %
- Max. Air volume: 250 m³/h
- Minimum air flow: 135 m³/h
- Loudness at max. speed (2010/30/EC)68 dB
- Loudness at min. speed (2010/30/EC)53 dB
- Sound power dB68 dB(A) re 1 pW
- Energy intelligent device, can optimize consumption behavior (2017/1369/EU): no
- wireless communication possible: no
- network broadband technology: not applicable
- SIM card slot available: no
- Type of interface for control: no
- Remote upgrade possibility: no
- Possibility of remote update for maintenance: no
- Possibility for voice controlno
- Manual controlsslide switch
- Remote control: no
- Total fan power: 115 W
- Max. Fan power - exhaust air mode: 250 m³/h
- Max. Fan power - recirculation mode: 80 m³/h
- Lighting efficiency (2010/30/EC): On/Off
- Total light intensity: 45 lux
- Grease filter material: non-washable synthetic
- diameter exhaust port: 12 cm
- Type of grease filter: mat
- Backflow flapyes
- Odor filter: no
- COMBInEd_nOMenCLATURE_COdE: 84146000
