Constructa CD106151, under-unit hood, 60 cm, stainless steel
Performance and consumption
- Energy efficiency class: D (on an energy efficiency class scale from A+++ to D)
- Average energy consumption: 69.3 kWh/year* < li>Fan efficiency class: E*
- Lighting efficiency class: E*
- Grease filter efficiency class: D*
- For installation under a wall cupboard or
- on the wall
- Swivelling vapor guide screen made of glass
- For exhaust air or recirculation mode< /li>
- A standard activated carbon filter is required for recirculation mode (special accessory)
- Fan power can be adjusted to 3 levels using
- Slide switch
- Even, bright lighting with 1 x 1.5 W LED module
- Illuminance: 45 lux
- Color temperature: 3000 K
- Fleece filter
- Exhaust air connection Ø 120 mm (Ø 100 mm included)
- Special Accessories:
- <200065val>
- Device dimensions (HxWxD): 150 x 600 x 482 mm
- Device dimensions, exhaust air (HxWxD): 150-150 x 600 x 482 mm < li>Device dimensions for circulating air (HxWxD): 150-150 x 600 x 482 mm
- Total connected load: 119 W
- Voltage: 220 - 240 V
- Max. Flow rate: 250 m3/h
- Min./max. noise. Normal level: 53/68 dB
- Fan performance according to EN 61591
- in exhaust air mode max. 250m³/h
- in recirculation mode max.80m³/h < li>Noise values according to EN 60704-3 and EN 60704-2-13 max. normal level:
- Exhaust air operation: 68 dB(A) re 1 pW (54dB(A) re 20 µPa sound pressure)
- Recirculating air mode: 77 dB(A) re 1 pW (63 dB(A) re 20 µPa sound pressure)
- 60 cm li>
Energy efficiency class: | D |
Product type: | extractor hood |
Color: | stainless steel |
Controls: | Slide switchWithout |
Installation type: | Under-counter device |
Device width: | 60cm |
Shipping weight: | 10,00 kg |
Item weight: | 6,00 kg |
Dimensions ( Length × Width ): | 48,20 × 60,00 cm |
- Color of the device: Stainless steel
- Basic color of the product< /b>: Not applicable
- Colour of casing: Stainless steel
- Specify material of casing: Stainless steel
- Design: Fan module/intermediate/substructure hood
- Control: Mechanical
- Design: Built-in
- Type of installation: Under-counter unit
- Controls: Without, slide switch
- Decorative< /b>: Not applicable
- Location of fan: Motor in housing
- Type of air duct: Convertible < li>Connected load: 119 W
- Voltage: 220-240 V
- Minimum voltage: 220 V
- Maximum voltage: 240 V
- Frequency: 50 TPU00040
- Minimum frequency b>: 50
- Maximum frequency: 50
- Length of connection cable: 145.0 cm
- Plug type: Schuko/Gardy.with earthing
- Device width: 60 cm
- Device depth: 48, 2 cm
- Height of packaged device: 26.7 cm
- Width of packaged device: 65.2 cm
- Depth packed product: 74.8 cm
- Net weight: 6.8 kg
- Gross weight< /b>: 10.7 kg
- Application of the EU Energy Consumption Directive: Yes
- Avg. Annual energy consumption: 69.3 kWh/year
- Fluid dynamics efficiency (2010/30/EU): 8.1
- Lighting efficiency (2010/30/EC): 11.0 lux/Watt
- Grease filter efficiency (2010/30/EU): 65.1%
- Max. Air volume: 250 m³/h
- Minimum air flow: 135 m³/h
- Volume at max. speed (2010/30/ EC): 68 dB
- Volume at min. speed (2010/30/EC): 53 dB
- Energy consumption in switched off mode (2010/30/EU): 0.00 W
- Sound power dB: 68 dB(A) re 1 pW
- Energy-intelligent device, can optimize consumption behavior (2017/1369/EU): No
- Wireless communication possible: No
- Network -Broadband technology: Not applicable
- SIM card slot available: No
- Type of interface for control: No
- Ability to remotely upgrade: No
- Ability to remotely update for maintenance: No
- Voice control option: No
- Manual controls: Slide switch
- Remote control: No< /li>
- Total fan power: 115 W
- Max. Fan performance - exhaust air mode: 250 m³/h
- Max. Fan power - recirculation mode: 80 m³/h
- Lighting efficiency (2010/30/EC): On/Off
- Total light intensity: 45 lux
- Grease filter material: Non-washable synthetic
- Exhaust air nozzle diameter: 10 cm
- Type of grease filter: Matte
- Backflow flap: No
- Odour filter: No
- COMBINED_NOMENCLATURE_CODE: 84146000
