Siemens lu62lfa51, iQ100, under-cabinet hood, 60 cm, stainless steel
Design
- Infinitely adjustable air deflector
- made of glass
- For mounting under a wall cabinet or on the wall
- Optionally exhaust air or recirculated air operation
- For recirculation operation, a standard activated carbon filter is required (optional accessory)
- 3 power levels
- Exhaust air capacity according to en 61591:
- max.250 m³/h
- Max. Delivery rate: 250 m3/h
- Exhaust air spigot ø 120 mm, 100 mm
- average energy consumption: 69.3 kWh/year*
- Energy efficiency class: d (on an energy efficiency class scale from a+++ to d)
- Fan efficiency class: E*
- Lighting efficiency class: E*
- Grease filter efficiency class: d*
- Noise min./max. normal level: 53/68 dB
- Noise values according to en 60704-3 and en 60704-2-13 max. normal level exhaust air mode: 68 dB(A) re 1 pW (54 dB(A) re 20 ?Pa sound pressure)
- Workplace lighting with 1 x LEd 4w E14
- Illuminance: 45 lux
- Color temperature: 3000 K
- Dimensions (HxWxD): 150 x 600 x 482 mm
- Total connected load: 119 W
| Energy efficiency class: | D |
| Colour: | Stainless steel |
| Product type: | Extractor bonnet |
| Installation type: | Sub-unit |
| device width: | 60 cm |
| controls: | Without Slide switch |
| Shipping weight: | 9,00 kg |
| Item weight: | 5,00 kg |
| Dimensions ( Length × Width ): | 48,20 × 60,00 cm |
- Product series: iQ100
- Color appliancestainless steel
- Basic product color: Not applicable
- Housing color: Stainless steel
- Specify case material: Stainless steel
- Construction type: Fan module/intermediate/undermount hood
- Control: Mechanical
- Design: Built-in
- Type of installation: Sub-assembly unit
- Controls: Without, slide switch
- decorable: Not applicable
- Fan position: Motor in housing
- Type of air duct: Convertible
- Connected load: 119 W
- Voltage: 220-240 V
- Frequency50 TPU00040
- Length connection cable145 cm
- Plug type: Schuko/Gardy.w.grounding
- Device width60 cm
- Device depth: 48,2 cm
- Packed unit height26,7 cm
- Width packed unit65,2 cm
- Depth packed product74,8 cm
- Net weight: 6,7 kg
- Gross weight: 10,7 kg
- Height chimney exhaust air max.: 15 cm
- Height chimney exhaust air min.: 15 cm
- Height chimney recirculation max.15 cm
- Height chimney recirculation min.15 cm
- average annual energy consumption: 69.3 kWh/year
- Liquid dynamic efficiency (2010/30/EU): 8.1
- Lighting efficiency (2010/30/EC)11.0 lux/watt
- Grease filter efficiency (2010/30/EU): 65.1 %
- Max. Air volume: 250 m³/h
- Minimum air flow: 135 m³/h
- Loudness at max. speed (2010/30/EC)68 dB
- Loudness at min. speed (2010/30/EC)53 dB
- Sound power dB68 dB(A) re 1 pW
- Energy intelligent device, can optimize consumption behavior (2017/1369/EU): No
- wireless communication possible: No
- Network broadband technology: Not applicable
- SIM card slot available: No
- Control interface typeno
- Possibility of remote upgrade: No
- Possibility of remote update for maintenance: No
- Possibility of voice controlno
- Manual controlsslide switch
- Remote Controlno
- Total fan power: 115 W
- Max. Fan capacity - exhaust air mode: 250 m³/h
- Max. Fan power - recirculation mode: 80 m³/h
- Lighting efficiency (2010/30/EC): On/Off
- Total light intensity: 45 lux
- Grease filter material: Non washable synthetic
- exhaust port diameter: 10 cm
- Type of grease filter: Mat
- Backflow flapyes
- Odor filterno
- COMBINEd_NOMenCLATURE_COdE: 84146000
