Gaggenau rc282306, 200 series, built-in refrigerator, 177.5 x 56 cm
- 3 climate zones incl. 3 fresh food drawers near 0 °c
- Height adjustable shelves made of safety glass
- Door shelves with aluminum profiles
- Can be combined with freezer rf 282 (side-by-side)
- Damped door retraction system allows for smooth and controlled closing
- 3 climate zones incl. 3 fresh food drawers close to 0 °c
- Height adjustable safety glass shelves
- Door shelves with aluminum profiles
- Can be combined with freezer rf 282 (side-by-side)
- Damped door retraction system enables smooth and controlled closing
- Total capacity 289 liters
- Electronic temperature control with digital display.
- Sensor buttons.
- automatic defrost with defrost water evaporation.
- Damped door retraction system from 20° door opening angle, integrated in the door hinge.
- alarm in case of open door or malfunction.
- Home network integration for digital services (Home Connect) wireless via WiFi.
- the use of the Home Connect function depends on the Home Connect services, which are not available in every country. For more information, visit home-connect.com.
- Fast cooling.
- Temperature adjustable from +3 °c to +8 °c.
- 6 height-adjustable safety glass shelves, 1 of which is extendable.
- 1 shelf.
- Wine and champagne rack for 4 bottles, fully foldable.
- 1 large door rack with aluminum profile for bottles. Bottle rack, sliding.
- 4 door racks with aluminum profile.
- Bright interior lighting with glare-free LEd lighting element, integrated on the side.
- Useful capacity 206 liters.
- 1 fully extendable fresh cooling drawer close to 0 °c, illuminated.
- Humidity manually adjustable.
- Ideal for fruit and vegetables.
- 2 fully extendable fresh refrigerated drawers near 0 °c, illuminated.
- Ideal for meat, fish and poultry.
- Useful capacity 83 liters.
- Energy efficiency class d on a scale of efficiency classes from a to G.
- Energy consumption 120 kWh/year.
- Noise value 36 dB (a) re 1 pW.
- Flat hinge.
- Door hinge right, changeable.
- Door opening angle 115°, fixable to 90°.
- Max. permissible door front weight 22 kg.
- For side-by-side installation, each unit must be planned in its own niche.
- Total connected load 0.090 kW.
- connection cable 2.3 m with plug.
| Energy efficiency class: | A+++ D |
| Product type: | Refrigerator |
| Installation type: | Fully integrable |
| device width: | 60 cm |
| controls: | Warning signal door open Temperature display for cooling Superswitch cooling |
| Shipping weight: | 73,00 kg |
| Dimensions ( Length × Width × Height ): | 54,50 × 55,80 × 177,20 cm |
- Product series: 200 series
- Product categoryrefrigerator
- Product type1-door
- Type of construction: Built-in
- Controlelectronic
- type of installation: Fully integrated
- Controls: Super switch cooling, Temperature indicator for cooling, Warning signal door open
- Color appliance: Not applicable
- decorable: Not possible
- connected load: 90 W
- fuse protection: 10
- Voltage: 220-240 V
- Frequency50 TPU00040
- approval certificatescE
- Length of connection cable230 cm
- Type of plugschuko/Gardy. with grounding
- Net capacity: 289 l
- Gross capacity refrigerator: 313 l
- Unit height177,2 cm
- Unit width55,8 cm
- Unit depth54,5 cm
- Product depth with door open (90°)114 cm
- Door hinge: Changeable to the right
- Height adjustable feetno
- Height packed unit184 cm
- Width packed unit61 cm
- Depth packed product64 cm
- Minimum niche height177,5 cm
- Maximum niche height177,5 cm
- Minimum niche width56 cm
- Maximum niche width56 cm
- Niche depth55 cm
- Net weight: 68,4 kg
- Gross weight: 73,8 kg
- Total volume of cold storage compartments (eu 2017/1369): 289 l
- Total volume of the product (eu 2017/1369): 289 l
- type of defrosting technology (cold storage compartment) (eu 2017/1369): automatic
- Volume of the compartment (cold storage compartment) (eu 2017/1369): 83.0 l
- average energy consumption in kilowatt hours per year (kWh/a) (eu 2017/1369): 120 kWh/a
- Energy efficiency index (eu 2017/1369): 79.0
- Quick freeze" function (eu 2017/1369): No
- Volume of the compartment (storage compartment for fresh food) (eu 2017/1369): 206.0 l
- type of defrosting technology (fresh food storage compartment) (eu 2017/1369): automatic
- type of light source (eu 2019/1805): LEd
- Low noise refrigerator: no
- Maximum ambient temperature (eu 2017/1369): 43 °c
- Minimum ambient temperature (eu 2017/1369): 10 °c
- Airborne sound emissions (eu 2017/1369): 36 dB(a) re 1 pW
- Product excluded from the scope for "low noise appliance" and "wine storage cabinet" (eu 2017/1369): No
- QR code (eu 2017/1369): HTTPS://EPREL.EC.EUROPa.EU/QR/260964
- Wine storage cabinet only: No
- Control function ?Winter switching" for combi unit (eu 2017/1369): No
- Energy smart appliance, can optimize consumption behavior (2017/1369/EU): No
- wireless communication possible: Yes, built into the unit
- Network broadband technology: Not applicable
- SIM card slot availableno
- Communication technology usedwiFi
- type of interface for control: LaN
- Remote upgrade possibilityno
- Possibility of remote update for maintenance: Yes
- Camera present in deviceno
- Warning signal in case of malfunctionno signal
- Fast cooling functionyes
- Fast freeze functionno
- Door open indicator freezeryes
- Internal fan refrigeratorno
- Furniture door mounting: Fixed mounted
- Bottle rackyes
- lockable doorno
- Material shelves: glass, plastic
- Temperature display refrigeratordigital
- Temperature display freezerwithout
- Included accessories: 3 x egg rack, 1 x wine and champagne rack
- Adjustable temperatureyes
- Temperature adjustable freezer compartmentno
- Defrost water drying: No
