neff d46ed52x1, n 50, flat screen hood, 60 cm, silver metallic, 360,00 €

neff d46ed52x1, n 50, flat screen hood, 60 cm, silver metallic

SKU: D46ED52X1 | GTIN: 4242004251125

Flat screen hood: the flat screen hood makes itself practically invisible in the wall unit and is ideal for clear kitchen fronts

Handle bar - select the accessory in your desired color
High exhaust performance: ensures a clear view when cooking thanks to efficient motor technology as an exhaust or recirculation solution.
EfficientDrive motor technology - quiet and energy-efficient hood motor for more quietness in the kitchen.
Intensive stage: increases fan power in case of heavy cooking fumes
LED light - everything lights up while cooking.

A A+++ ↑ D

360,00 €

from

Product datasheet

Only 352,80 € by payment in advance
less 2% discount

incl. 19% VAT , Free shipping

Delivery time: 8 - 10 Workdays

Garantieverlängerung

1x 5 years warranty

+60,00 €

Nothing found?

You could not find your desired device yet or you need a device of the manufacturers shown above? Then please tell us the desired item numbers and we will send you a non-binding offer.

Submit device request now

Design

60 cm
Can be installed in 60 cm wide wall unit
optionally exhaust or recirculation operation
For recirculation operation, a standard recirculation set or a Clean air Plus recirculation set (optional accessory) is required

DesignComfort

Short-stroke buttons with LED display
High, finely adjustable air output thanks to electronic control via short-stroke keys with LED display
High, finely metered air output via electronic control system
Short-stroke keys (3 power levels and
1 intensive stage) with LED display
Electronic control on the side
Short-stroke keys
3 power levels and
1 intensive level
Intensive levels with automatic reset
automatic fan run-on with digital display

equipment

Uniform, bright illumination with 2 x 1.5 w LED module
Color temperature: 3500 K
Illuminance: 294 lux
Stainless steel filter cover, dishwasher safe
Metal grease filter, dishwasher safe

Operating mode and power

Fan capacity for exhaust air operation according to en 61591:
max. normal stage399 m³/h, intensive stage 728 m³/h
When using the separately available Clean air Plus recirculation set (optional accessory), your appliance achieves the following values in recirculation mode:
Recirculation stage: Max. normal operation:358m³/h
Intensive stage:628m³/h
Noise level recirculation: Max. normal mode:60dB(a) re 1 pw
Intensive stage:71 dB(a) re 1 pw
Noise values according to en 60704-2-13 for exhaust air operation:
Max. normal level:53dB(a) re 1 pw
Intensive stage:68 dB(a) re 1 pw
Noise min./max. normal stage: 41/53 dB
2 single-flow standing. bldc motor
bldc motor

Planning and installation information

Quick mounting bracket
Unit dimensions (HxWxD): 426 x 598 x 290 mm
Installation dimensions (HxWxD): 385 x 524 x 290 mm
exhaust air connection ø 150 mm (ø 120 mm enclosed)
with backflow flap
Length of connection cable: 1.75 m with plug
without handle (available as optional accessory)

Environment and safety

Energy efficiency class: a (on an energy efficiency class scale from a+++ to D)
Average energy consumption: 37.9 kwh/year*
Fan efficiency class: B*
Lighting efficiency class: a*
Grease filter efficiency class: B*
Total connected load: 144 w

Energy efficiency class:	A
Colour:	Silver metallic
Product type:	Extractor bonnet
Installation type:	Integrable Built-in
device width:	60 cm
controls:	SSD-??????? LED Short-stroke keys SSD-???????
Shipping weight:	11,00 kg
Item weight:	10,00 kg
Dimensions ( Length × Width ):	29,00 × 59,80 cm

Product series: n 50
Color appliance: Silver metallic
Basic color of the product: not applicable
Housing color: Silver metallic
Specify material of housing: galvanized
Type of construction: flat screen hood
Control: electronic
Design: Built-in
type of installationbuilt-in
Operating elements: Short travel keys, LED
Decorative: not applicable
Fan position: motor in housing
type of air duct: Convertible
connected load: 144 w
fuse protection: 10
Voltage: 220-240 V
Frequency: 50; 60 TPU00040
Length connection cable175 cm
Plug type: Schuko/Gardy.w.grounding
Width of the device59,8 cm
Device depth29 cm
Packed unit height40 cm
Width packed unit64 cm
Depth packed product49 cm
minimum niche width52,4 cm
maximum niche width52,4 cm
niche depth29 cm
net weight: 10,0 kg
Gross weight: 11,9 kg
Height chimney exhaust max.: 42,6 cm
Height chimney exhaust air min.: 42,6 cm
Height chimney recirculation max.42,6 cm
Height chimney recirculation min.42,6 cm
Average annual energy consumption: 37.9 kwh/year
Liquid dynamic efficiency (2010/30/EU): 27.8
Lighting efficiency (2010/30/EC)70.0 lux/watt
Grease filter efficiency (2010/30/EU): 88.5 %
Max. Air volume: 399 m³/h
Minimum air flow: 211 m³/h
Air flow amplified (2010/30/EU): 728 m³/h
Loudness at max. speed (2010/30/EC)53 dB
Loudness at min. speed (2010/30/EC)41 dB
Volume amplified (2010/30/EC)68 dB
Energy consumption in standby mode (2010/30/EC): 0.20 w
Sound power dB: 53 dB(a) re 1 pw
Noise level with fast cooking position (booster)68 dB(a) re 1 pw
Energy intelligent appliance, can optimize consumption behavior (2017/1369/EU): no
Wireless communication possible: no
network broadband technology: not applicable
SIM card slot available: no
type of interface for control: no
Possibility of remote upgrade: no
Possibility of remote update for maintenance: no
Possibility of voice controlno
Manual controls: short stroke keys
Remote controlno
Total fan power: 140 w
Max. Fan capacity - exhaust air mode399 m³/h
Max. fan power at intensive stage - exhaust air mode: 728 m³/h
Max. Fan capacity - recirculation mode: 358 m³/h
Max. fan power at intensive stage - recirculation mode: 628 m³/h
Lighting efficiency (2010/30/EC): on/off
Total luminous intensity: 294 lux
Grease filter material: stainless steel washable
Diameter exhaust port: 12 cm
type of grease filtercassette
Backflow flapyes
Odor filter: no
type of lights used: LED
COMBInED_nOMenCLaTURE_CODE: 84146000
