Siemens li67ra561, iQ500, Flat screen hood, 60 cm, stainless steel
Design
- 60 cm
- For special wall cabinets (60 cm wide)
- optionally exhaust or recirculation mode
- For recirculation operation, a standard recirculation set or a Clean air Plus recirculation set (optional accessory) is required
- Electronic control with filter change indicator
- Electronic control via Electronic control with filter change indicator
- Electronic control
- Electronic control (3 power levels + 2 intensive levels) with filter change indicator
- Electronic control with 6 buttons and display
- Electronic control
- 3 power levels + 2 intensive levels
- Intensive levels with automatic reset
- automatic fan run-on
- Uniform, bright illumination with 2 x 1.5 w LED module
- Dimming function
- softLight
- Color temperature: 3500 K
- Illuminance: 294 lux
- Stainless steel filter Cover, perforated and Dishwasher safe
- Metal grease filter, Dishwasher-safe
- Saturation indicator for grease and odor filter
- Fan capacity for exhaust air operation according to en 61591:
- max. normal stage392 m³/h, intensive stage 717 m³/h
- Noise values according to en 60704-2-13 for exhaust air operation:
- Max. Normal level:53dB(a) re 1 pw
- Intensive stage:68 dB(a) re 1 pw
- Noise min./max. normal stage: 41/53 dB
- When using the separately available Clean air Plus recirculation set (optional accessory), your appliance achieves the following values in recirculation mode:
- Recirculation stage: max. Normal operation:358m³/h
- Intensive stage:628m³/h
- Noise values recirculation: Max. Normal mode:60dB(a) re 1 pw
- Intensive stage:71 dB(a) re 1 pw
- 2 single-flow standing. Energy-saving operation with iQdrive motor technology
- Energy-saving operation with iQdrive motor technology
- Quick mounting fastening
- Unit dimensions (HxWxD): 426 x 598 x 290 mm
- Installation dimensions (HxWxD): 385 x 524 x 290 mm
- exhaust air connection ø 150 mm (ø 120 mm enclosed)
- Length of connection cable: 1.75 m with plug
- without handle (available as optional accessory)
- Energy efficiency class: a (on an energy efficiency class scale from a+++ to D)
- Average energy consumption: 37.8 kwh/year*
- Fan efficiency class: B*
- Lighting efficiency class: a*
- Grease filter efficiency class: B*
- Total connected load: 144 w
Color: | stainless steel |
Product type: | extractor hood |
Installation type: | Built in |
Device width: | 60cm |
Controls: | 7 segment displayShort-stroke keys7-Segment-Anzeige;Kurzhubtasten |
Shipping weight: | 13,00 kg |
Item weight: | 11,00 kg |
Dimensions ( Length × Width × Height ): | 29,00 × 59,80 × 42,60 cm |
- Product series: iQ500
- Color appliancestainless steel
- Basic product color: Not applicable
- Housing color: Stainless steel
- Specify case material: Stainless steel
- Construction type: Flat screen hood
- Control: Electronic
- Design: Built-in
- type of installationbuilt-in
- Controls: 7-segment display, short-travel keys
- Decorative: Not applicable
- Blower position: Motor in housing
- type of air duct: Convertible
- connected load: 144 w
- fuse protection: 10
- Voltage: 220-240 V
- Frequency: 50; 60 TPU00040
- Length connection cable175 cm
- Plug type: Schuko/Gardy.w.grounding
- Width of the device59,8 cm
- Device depth29 cm
- Packed unit height40 cm
- Width packed unit64 cm
- Depth packed product49 cm
- Minimum niche width52,4 cm
- Maximum niche width52,4 cm
- Niche depth29 cm
- Net weight: 11,1 kg
- Gross weight: 13,0 kg
- Height chimney exhaust max.: 42,6 cm
- Height chimney exhaust air min.: 42,6 cm
- Height chimney recirculation max.42,6 cm
- Height chimney recirculation min.42,6 cm
- Average annual energy consumption: 37.8 kwh/year
- Liquid dynamic efficiency (2010/30/EU): 27.2
- Lighting efficiency (2010/30/EC)62.6 lux/watt
- Grease filter efficiency (2010/30/EU): 87.2 %
- Max. Air volume: 392 m³/h
- Minimum air flow: 208 m³/h
- Air flow amplified (2010/30/EU): 717 m³/h
- Loudness at max. speed (2010/30/EC)53 dB
- Volume at min. speed (2010/30/EC)41 dB
- Volume amplified (2010/30/EC)68 dB
- Energy consumption in standby mode (2010/30/EC): 0.30 w
- Sound power dB: 53 dB(a) re 1 pw
- Noise level with fast cooking position (booster): 68 dB(a) re 1 pw
- Energy smart appliance, can optimize consumption behavior (2017/1369/EU): No
- Wireless communication possible: No
- Network broadband technology: Not applicable
- SIM card slot available: No
- type of control interfaceno
- Remote upgrade possibilityno
- Possibility of remote update for maintenance: No
- Possibility of voice controlno
- Manual controls: Short-stroke keys
- Remote Controlno
- Total fan power: 140 w
- Max. Fan capacity - exhaust mode392 m³/h
- Max. fan power at intensive stage - exhaust air mode: 717 m³/h
- Max. Fan capacity - recirculation mode: 358 m³/h
- Max. fan power at intensive stage - recirculation mode: 628 m³/h
- Lighting efficiency (2010/30/EC): Stepless
- Total luminous intensity: 294 lux
- Grease filter material: Stainless steel washable
- Diameter exhaust port12 cm
- type of grease filtercassette
- Backflow flapyes
- Odor filterno
- number of speed settings: 3 levels + 2 intensive
- type of lights used: LED
- COMBINED_NOMenCLaTURE_CODE: 84146000
