Bosch DFL094A51, Series 4, flat screen hood, 90 cm, silver, metallic
Design
- 90 cm
- 90 cm flat screen hood, gray metallic
- For installation in a 60 cm or 90 cm wide special wall cabinet
- Short stroke buttons with LED display
- Electronic control via short stroke buttons with LED display
- Electronic Control
- Short stroke buttons (3 power levels and
- 1 intensive level) with LED display
- Electronic control on the side
- Short stroke buttons < li>3 power levels and
- 1 intensive level
- Intensive levels with automatic reset
- Fan run-on 10 minutes
- Even, bright lighting with 3 x 1.5 W LED module
- Color temperature: 3500 K
- Illuminance: 355 lux
- Cassette with aluminum frame
- Metal grease filter, Dishwasher-safe
- Exhaust air performance according to EN 61591: max. 412 m³/h li>
- Fan performance according to EN 61591 for exhaust air operation:
- Max. Normal level: 266m³/h
- Intensive level: 412 m³/h
- Recirculating air output:
- max. Normal operation216m³/h
- Intensive level239 m³/h
- Noise levels according to EN 60704-2-13 for exhaust air operation:
- Max. Normal level: 63dB(A) right 1 pW
- Intensive level: 70 dB(A) right 1 pW
- Noise levels in recirculation mode:
- max. Normal level: 67dB(A) re 1 pW
- Intensive level: 69 dB(A) re 1 pW
- Choice of exhaust air or recirculation mode
- Recirculation mode becomes a standard Recirculation set (special accessory) required
- 1 single-flow. Eco Silence Drive - the powerful and energy-saving motor
- Eco Silence Drive - the powerful and energy-saving motor
- Device dimensions (HxWxD): 203 x 898 x 290 mm
- Installation dimensions (HxWxD): 162 x 526 x 290 mm
- Exhaust air socket Ø 150 mm (Ø 120 mm included)
- Length of connection cable: 1.75 m with plug
- Handle bar available as an optional accessory
- Energy efficiency class: A (on an energy efficiency class scale from A+++ to D)
- Average energy consumption: 22.2 kWh/year*
- Fan efficiency class: B*
- Lighting efficiency class: A*
- Grease filter efficiency class: C*
- Total connected load: 76 W
Energy efficiency class: | A |
Product type: | extractor hood |
Color: | Silver metallic |
Controls: | SSD-???????#1LEDShort-stroke keysSSD-??????? |
Installation type: | IntegrableBuilt in |
Device width: | 90cm |
Shipping weight: | 12,00 kg |
Item weight: | 10,00 kg |
Dimensions ( Length × Width ): | 29,00 × 89,80 cm |
- Product series b>: Series 4
- Color of device: Silver metallic
- Basic color of the product: Not applicable
- Colour of housing: silver metallic
- Specify material of housing: galvanized
- Type: flat screen hood li>
- Control: Electronic
- Design: Built-in
- Type of installation: Built-in
- Controls: Short-stroke buttons, LED
- Decorative: Not applicable
- Location fan : Motor in the housing
- Type of air duct: Convertible
- Connection load: 76 W < li>Fuse: 10
- Voltage: 220-240 V
- Minimum voltage: 220 V
- Maximum voltage: 240 V
- Frequency: 50; 60
- Minimum frequency: 50
- Maximum frequency: 60
- Length of connection cable: 175.0 cm
- Plug type: Schuko/Gardy.with earthing
- Device width: 89.8 cm li>
- Device depth: 29 cm
- Height of packaged device: 31 cm
- Width of packaged device< /b>: 94 cm
- Depth of packaged product: 36 cm
- Minimum niche width: 52.6 cm
- Maximum niche width: 52.6 cm
- Niche depth: 29 cm
- Net weight: 10.0 kg
- Gross weight: 12.3 kg
- Air outlet: Yes
- Avg. Annual energy consumption: 22.2 kWh/year
- Fluid dynamics efficiency (2010/30/EU): 23.7
- Lighting efficiency (2010/30/EC): 65.7 lux/Watt
- Grease filter efficiency (2010/30/EU): 81.8%
- Max. Air volume: 266 m³/h
- Minimum air flow: 164 m³/h
- Air flow increased (2010/30/EU)< /b>: 412.0 m³/h
- Volume at max. speed (2010/30/EC): 63 dB
- Volume at min . Speed (2010/30/EC): 50 dB
- Sound power dB: 63 dB(A) re 1 pW
- Noise level with quick cooking position (booster): 70 dB(A) re 1 pW
- Energy-intelligent device, can optimize consumption behavior (2017/1369/EU): No
- Wireless communication possible: No
- Network broadband technology: Not applicable
- SIM card slot available: No
- Type of interface for control: No
- Remote upgrade option : No
- Ability to remotely update for maintenance: No
- Ability to voice control: No
- Manual controls: Short-stroke buttons
- Remote control: No
- Total fan power: 70 W li>
- Max. Fan performance - exhaust mode: 266 m³/h
- Fan performance at intensive level - exhaust mode: 412 m³/h
- Max. Fan performance - recirculation mode: 263 m³/h
- Fan performance at intensive level - recirculation mode: 353 m³/h
- Lighting efficiency ( 2010/30/EC): On/Off
- Total light intensity: 355 lux
- Frease filter material: aluminum washable
- Diameter of exhaust air connection: 12 cm
- Backflow flap: No
- Odour filter b>: No
- Number of speed settings: 3 fan levels and 1 intensive level
- Type of lights used: LED
- COMBINED_NOMENCLATURE_CODE: 84146000
