Siemens LC81KAN60, iQ500, wall panel, 80 cm, clear glass printed black
Design:
- Inclined dining room
- Wall mounting
- Glass pane: printed in black
- Choice of exhaust air or recirculation mode
- Chimney-free operation possible with recirculation
- The Clean Air Plus recirculation set (accessory) or the Longlife recirculation set (accessory) is used for recirculation operation. needed.
- iQdrive motor - quiet and powerful motor
- Lighting: 2 pieces, LED, 3 W, with color temperature adjustable
- softLight: the lighting switches on and off gently.
- Dimming function: the brightness of the lighting can be adjusted.
- Color temperature: 3500 K
- Illuminance: 422 lux
- Boost position: intermediate positions of the glass filter Cover to better extract particularly strong cooking odors and amounts of steam.
- Extractor hood on the front and bottom
- 3 metal grease filters
- touchControl
- 3 power levels and
- 1 intensive level
- Automatic Fan overrun
- Automatic reset from intensive to normal level after 6 minutes.
- Home Connect: Operation, checking and setting of your hood via smartphone or tablet (only in countries where the Home Connect Service is available)
- The cookConnect system automatically activates the extractor hood when cooking, thanks to the WiFi connection of the extractor hood and a suitable one Hob.
- Hob-hood connection: The extractor hood automatically adjusts the fan speed as the Hob continuously provides cooking data (with a suitable hob and connected Home Connect access)
- Fully automatic extractor hood
- Voice control possible via common voice assistants
- Performance profiles: Choose between standard, performance or quiet in the Home Connect app to increase the extraction power or reduce the fan noise
- LED lighting with adjustable light temperature: Allows you to adjust the light temperature to your personal needs via the Home Connect app
- Saturation display, setting and reset function for grease filters and odor filters available via the Home Connect app.
- Running function: available via the Home Connect app
- Interval function: available via the Home Connect app
- The Home Connect functionality can be achieved by integrating numerous applications external cooperation partner (partnering) expand as desired
- Upgradable device (available with a connected Home Connect account): Always keep the device up to date with the latest software.
- The surfaces and materials are smooth and easy to clean.
- Inner frame, easy to clean
- Metal grease filter, Dishwasher safe
- According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values in exhaust air mode:
- Performance level 1: Fan performance: 223 m3/h; Noise value 35 dB(A) re1pW
- Performance level 2: Fan performance: 320 m3/h; Noise value 43 dB (A) re1pW
- Performance level 3: Fan performance: 432 m3/h; Noise value 51 dB (A) re1pW
- Intensive level 1: Fan performance: 915 m3/h; Noise value 68 dB (A) re1pW
- Energy efficiency class: A+ (on an energy efficiency class scale from A+++ to D)
- Average energy consumption: 35.5 kWh/year*
- Fan efficiency class: A*
- Lighting efficiency class: A*
- Grease filter efficiency class: C*
- According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values in recirculation mode with the Clean Air plus recirculation set for installation with a chimney:
- Performance level 1: Fan performance: 212 m3/h; Noise value: 42 dB(A) re1pW
- Performance level 2: Fan performance: 315 m3/h; Noise value: 51 dB(A) re1pW
- Performance level 3: Fan performance: 433 m3/h; Noise value: 59 dB(A) re1pW
- Intensive level 1: Fan performance: 896 m3/h; Noise value: 76 dB (A) re1pW
- According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values in recirculation mode with the Clean Air plus recirculation set for chimney-less installation:
- Performance level 1: Fan performance: 215 m3/h; Noise value: 42 dB(A) re1pW
- Performance level 2: Fan performance: 315 m3/h; Noise value: 51 dB(A) re1pW
- Performance level 3: Fan performance: 438 m3/h; Noise value: 60 dB(A) re1pW
- Intensive level 1: Fan performance: 886 m3/h; Noise value: 78 dB (A) re1pW
- Consumption information:
- Total connected load: 200 W
- Voltage: 220 - 240 V
- Sustainability:
- Made in Germany: manufactured in a CO2-neutral production facility
- Environmentally friendly Packaging
- The most efficient fan technology on the market
- Available odor filter as a regenerable long life filter with a Service life of 10 years
- Hob-hood connection for best results with minimal energy consumption
- Device dimensions exhaust air (HxWxD): 855-1098 x 790 x 447 mm
- Device dimensions, recirculating air (HxWxD): 892-1185 x 790 x 447 mm
- Dimensions of recirculating air installation, chimneyless (HxWxD): 471 mm x 790 mm x 447 mm
- Simple and weight-reduced installation thanks to the new easy installation system
- Exhaust air socket Ø 150 mm
- Length of connection cable: 1.3 m with plug
- Delivery with backflow flap
Energy efficiency class: | A+ |
Color: | Black#1 |
Product type: | extractor hood |
Installation type: | Wall mounting |
Device width: | 80cm |
Controls: | LED; touch controlLEDTouchControl |
Shipping weight: | 36,00 kg |
Item weight: | 24,00 kg |
Dimensions ( Length × Width × Height ): | 44,70 × 79,00 × 45,00 cm |
Carl-Wery-Straße 34
Bayern
München, Deutschland, 81739
www.bsh-group.com
https://www.bsh-group.com
- Product series: iQ500
- Color of device: Black
- Basic color of the product: Not applicable
- Color of housing: Black
- Fireplace material: Black
- Design: Wall mounting
- Control: Electronic
- Design: Built-in
- Type of installation: Wall mounting
- Controls: LED;TouchControl
- Decorative: Not applicable
- Location of fan: Motor in housing
- Type of air flow: Convertible
- Connection load: 200 W
- Fuse: 10
- Voltage: 220-240 V
- Minimum voltage: 220 V
- Maximum voltage: 240 V
- Frequency: 50; 60
- Minimum frequency: 50
- Maximum frequency: 60
- Length of connection cable: 130.0 cm
- Plug type: Schuko/Gardy.m.earthing
- Device height: 45 cm
- Device width: 79 cm
- Device depth: 44.7 cm
- Height of packaged device: 77 cm
- Width of packaged device: 73 cm
- Depth of packaged product: 123 cm
- EPREL Registration Number 2010: 1851987
- Net weight: 24.9 kg
- Gross weight: 36.2 kg
- Air outlet: Yes
- Height of chimney exhaust air max.: 66.3 cm
- Height of chimney exhaust air min.: 42 cm
- Height of chimney circulating air max.: 75 cm
- Height of chimney circulating air min.: 45.7 cm
- Energy efficiency class (2010/30/EU): A+
- Avg. Annual energy consumption: 35.5 kWh/year
- Fluid dynamic efficiency (2010/30/EU): 39.7
- Lighting efficiency (2010/30/EC): 58.6 lux/watt
- Grease filter efficiency (2010/30/EU): 81.4%
- Max. Air volume: 432 m³/h
- Minimum air flow: 223.2 m³/h
- Air flow increased (2010/30/EU): 915.0 m³/h
- Volume at max. speed (2010/30/EC): 51 dB
- Volume at min. speed (2010/30/EC): 35 dB
- Sound power dB: 51 dB(A) re 1 pW
- Noise level with quick cooking position (booster): 68 dB(A) re 1 pW
- Energy-intelligent device, can Optimize consumption behavior (2017/1369/EU): No
- Wireless communication possible: Yes, built into the device
- Network broadband technology: Not applicable
- SIM card slot available: No
- Communication technology used: Bluetooth;WiFi
- Type of interface to Control: LAN
- Possibility for remote upgrade: Yes
- Possibility for remote update for maintenance: Yes
- Possibility for voice control: Yes, with optional Accessories
- Manual controls: TouchControl
- Remote Control: No
- Total fan power: 190 W
- Max. Fan performance - exhaust mode: 432 m³/h
- Fan performance at intensive level - exhaust mode: 915 m³/h
- Max. Fan power - recirculation mode: 438 m³/h
- Fan power at intensive level - recirculation mode: 886 m³/h
- Lighting efficiency (2010/30/EC): Gradual
- Total light intensity: 422 lux
- Grease filter material: Washable stainless steel
- Exhaust air connection diameter: 15 cm
- Backflow flap: Yes
- Odour filter: No
- Number of speed settings: 3 fan levels and 1 Intensive level
- COMBINED_NOMENCLATURE_CODE: 84146000
