Siemens LC81KAN60, iQ500, wall panel, 80 cm, clear glass printed black

  • SKU: LC81KAN60
  • GTIN: 4242003927076
Europe's most powerful slant in recirculation mode with iQdrive motor and air quality sensor for an intelligent, odorless and low-noise kitchen.
  • Europe's most powerful slant in recirculation mode
  • iQdrive motor: the quiet, powerful motor for efficient extraction of odors and vapors.
  • Intelligent Automatic extractor hood: the perfect interaction between hob and extractor hood for more cooking comfort.
  • cookConnect system: regulate the power levels and lighting of the extractor hood directly on the hob.
  • LED light with adjustable light temperature: adapt the lighting to your preferences and needs.
Siemens

Siemens LC81KAN60, iQ500, wall panel, 80 cm, clear glass printed black

Product datasheet (opens in new tab)
from
774,00 €
1.766,00 €**
(Save 56%, i.e. 992,00 €)

Only 758,52 € by payment in advance
less 2% discount

incl. 19% VAT , Free shipping

  • Delivery time: 8 - 10 Workdays (DE - int. shipments may differ)
Unit od ac

Sicher bezahlen

Nothing found?

You could not find your desired device yet or you need a device of the manufacturers shown above? Then please tell us the desired item numbers and we will send you a non-binding offer.

Submit device request now

Description

Design:
  • Inclined dining room
  • Wall mounting
  • Glass pane: printed in black
  • Choice of exhaust air or recirculation mode
  • Chimney-free operation possible with recirculation
  • The Clean Air Plus recirculation set (accessory) or the Longlife recirculation set (accessory) is used for recirculation operation. needed.
Most important features:
  • iQdrive motor - quiet and powerful motor
  • Lighting: 2 pieces, LED, 3 W, with color temperature adjustable
  • softLight: the lighting switches on and off gently.
  • Dimming function: the brightness of the lighting can be adjusted.
  • Color temperature: 3500 K
  • Illuminance: 422 lux
  • Boost position: intermediate positions of the glass filter cover to better extract particularly strong cooking odors and amounts of steam.
  • Extractor hood on the front and bottom
  • 3 metal grease filters
Comfort functions:
  • touchControl
  • 3 power levels and
  • 1 intensive level
  • Automatic Fan overrun
  • Automatic reset from intensive to normal level after 6 minutes.
Digital functions:
  • Home Connect: Operation, checking and setting of your hood via smartphone or tablet (only in countries where the Home Connect service is available)
  • The cookConnect system automatically activates the extractor hood when cooking, thanks to the WiFi connection of the extractor hood and a suitable one Hob.
  • Hob-hood connection: The extractor hood automatically adjusts the fan speed as the hob continuously provides cooking data (with a suitable hob and connected Home Connect access)
  • Fully automatic extractor hood
  • Voice control possible via common voice assistants
  • Performance profiles: Choose between standard, performance or quiet in the Home Connect app to increase the extraction power or reduce the fan noise
  • LED lighting with adjustable light temperature: Allows you to adjust the light temperature to your personal needs via the Home Connect app
  • Saturation display, setting and reset function for grease filters and odor filters available via the Home Connect app.
  • Running function: available via the Home Connect app
  • Interval function: available via the Home Connect app
  • The Home Connect functionality can be achieved by integrating numerous applications external cooperation partner (partnering) expand as desired
  • Upgradable device (available with a connected Home Connect account): Always keep the device up to date with the latest software.
Comfort when cleaning:
  • The surfaces and materials are smooth and easy to clean.
  • Inner frame, easy to clean
  • Metal grease filter, dishwasher safe
Performance Exhaust air:
  • According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values ​​in exhaust air mode:
  • Performance level 1: Fan performance: 223 m3/h; Noise value 35 dB(A) re1pW
  • Performance level 2: Fan performance: 320 m3/h; Noise value 43 dB (A) re1pW
  • Performance level 3: Fan performance: 432 m3/h; Noise value 51 dB (A) re1pW
  • Intensive level 1: Fan performance: 915 m3/h; Noise value 68 dB (A) re1pW
  • Energy efficiency class: A+ (on an energy efficiency class scale from A+++ to D)
  • Average energy consumption: 35.5 kWh/year*
  • Fan efficiency class: A*
  • Lighting efficiency class: A*
  • Grease filter efficiency class: C*
Recirculation air performance:
  • According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values ​​in recirculation mode with the Clean Air plus recirculation set for installation with a chimney:
  • Performance level 1: Fan performance: 212 m3/h; Noise value: 42 dB(A) re1pW
  • Performance level 2: Fan performance: 315 m3/h; Noise value: 51 dB(A) re1pW
  • Performance level 3: Fan performance: 433 m3/h; Noise value: 59 dB(A) re1pW
  • Intensive level 1: Fan performance: 896 m3/h; Noise value: 76 dB (A) re1pW
  • According to EN 61591 and EN/IEC 60704-2-13, your device can achieve the following values ​​in recirculation mode with the Clean Air plus recirculation set for chimney-less installation:
  • Performance level 1: Fan performance: 215 m3/h; Noise value: 42 dB(A) re1pW
  • Performance level 2: Fan performance: 315 m3/h; Noise value: 51 dB(A) re1pW
  • Performance level 3: Fan performance: 438 m3/h; Noise value: 60 dB(A) re1pW
  • Intensive level 1: Fan performance: 886 m3/h; Noise value: 78 dB (A) re1pW
Technical data and sustainability:
  • Consumption information:
  • Total connected load: 200 W
  • Voltage: 220 - 240 V
  • Sustainability:
  • Made in Germany: manufactured in a CO2-neutral production facility
  • Environmentally friendly Packaging
  • The most efficient fan technology on the market
  • Available odor filter as a regenerable long life filter with a service life of 10 years
  • Hob-hood connection for best results with minimal energy consumption
Information on planning and installation:
  • Device dimensions exhaust air (HxWxD): 855-1098 x 790 x 447 mm
  • Device dimensions, recirculating air (HxWxD): 892-1185 x 790 x 447 mm
  • Dimensions of recirculating air installation, chimneyless (HxWxD): 471 mm x 790 mm x 447 mm
  • Simple and weight-reduced installation thanks to the new easy installation system
  • Exhaust air socket Ø 150 mm
  • Length of connection cable: 1.3 m with plug
  • Delivery with backflow flap
Energy efficiency class: A+
Color: Black#1
Product type: extractor hood
Installation type: Wall mounting
Device width: 80cm
Controls: LED; touch controlPer AppPer App;Touch-SteuerungLEDTouchControl
Shipping weight: 36,00 kg
Item weight: 25,00 kg
Dimensions ( Length × Width × Height ): 44,70 × 79,00 × 45,00 cm

Technical data

  • Product series: iQ500
  • Color of device: Black
  • Basic color of the product: Not applicable
  • Color of housing: Black
  • Fireplace material: Black
  • Design: Wall mounting
  • Control: Electronic
  • Design: Built-in
  • Type of installation: Wall mounting
  • Controls: LED;TouchControl
  • Decorative: Not applicable
  • Location of fan: Motor in housing
  • Type of air flow: Convertible
  • Connection load: 200 W
  • Fuse: 10
  • Voltage: 220-240 V
  • Minimum voltage: 220 V
  • Maximum voltage: 240 V
  • Frequency: 50; 60
  • Minimum frequency: 50
  • Maximum frequency: 60
  • Length of connection cable: 130.0 cm
  • Plug type: Schuko/Gardy.m.earthing
  • Device height: 45 cm
  • Device width: 79 cm
  • Device depth: 44.7 cm
  • Height of packaged device: 77 cm
  • Width of packaged device: 73 cm
  • Depth of packaged product: 123 cm
  • EPREL Registration Number 2010: 1851987
  • Net weight: 24.9 kg
  • Gross weight: 36.2 kg
  • Air outlet: Yes
  • Height of chimney exhaust air max.: 66.3 cm
  • Height of chimney exhaust air min.: 42 cm
  • Height of chimney circulating air max.: 75 cm
  • Height of chimney circulating air min.: 45.7 cm
  • Energy efficiency class (2010/30/EU): A+
  • Avg. Annual energy consumption: 35.5 kWh/year
  • Fluid dynamic efficiency (2010/30/EU): 39.7
  • Lighting efficiency (2010/30/EC): 58.6 lux/watt
  • Grease filter efficiency (2010/30/EU): 81.4%
  • Max. Air volume: 432 m³/h
  • Minimum air flow: 223.2 m³/h
  • Air flow increased (2010/30/EU): 915.0 m³/h
  • Volume at max. speed (2010/30/EC): 51 dB
  • Volume at min. speed (2010/30/EC): 35 dB
  • Sound power dB: 51 dB(A) re 1 pW
  • Noise level with quick cooking position (booster): 68 dB(A) re 1 pW
  • Energy-intelligent device, can Optimize consumption behavior (2017/1369/EU): No
  • Wireless communication possible: Yes, built into the device
  • Network broadband technology: Not applicable
  • SIM card slot available: No
  • Communication technology used: Bluetooth;WiFi
  • Type of interface to Control: LAN
  • Possibility for remote upgrade: Yes
  • Possibility for remote update for maintenance: Yes
  • Possibility for voice control: Yes, with optional accessories
  • Manual controls: TouchControl
  • Remote Control: No
  • Total fan power: 190 W
  • Max. Fan performance - exhaust mode: 432 m³/h
  • Fan performance at intensive level - exhaust mode: 915 m³/h
  • Max. Fan power - recirculation mode: 438 m³/h
  • Fan power at intensive level - recirculation mode: 886 m³/h
  • Lighting efficiency (2010/30/EC): Gradual
  • Total light intensity: 422 lux
  • Grease filter material: Washable stainless steel
  • Exhaust air connection diameter: 15 cm
  • Backflow flap: Yes
  • Odour filter: No
  • Number of speed settings: 3 fan levels and 1 Intensive level
  • COMBINED_NOMENCLATURE_CODE: 84146000
