Constructa ca323255, Electric hob, 60 cm, With frame overlay
Flexibility of the cooking zones
- Roasting zone: Extra switchable cooking zone for large roasting utensils
- Dual-circuit cooking zone: use normal or larger cookware for the expandable cooking zone.
- 60 cm: Space for 4 pots or pans.
- Cooking zone front left: 180 mm, 2 kW
- Cooking zone rear left: 265 mm , 170 mm, 2.6 kW
- Cooking zone rear right: 145 mm , 1.2 kW
- Cooking zone front right: 210 mm, 145 mm, 2.2 kW
- Touch Control: control the power with the imprinted +/- touch buttons.
- 17 Power Levels: precisely adjust the heat with 17 power levels (9 main levels and 8 intermediate levels).
- Restart function: in case of unintentional power off of the cooktop, all settings will be retained if you turn it back on within 4 seconds.
- Quick shut-off: Quickly turn off by touching the cooking zone control surface for a longer time.
- with stainless steel frame
- 2-stage residual heat indicator per cooking zone: Shows which cooking zones are still hot or warm.
- Individually adjustable child safety lock: Prevents unintentional activation of the cooktop.
- Main switch: Turns off all cooking zones at once.
- Operation indicator lamp: Indicates whether the cooktop is heating.
- Automatic safety shut-off: For safety reasons, the cooktop switches off automatically after a preset time without interaction (adjustable).
- Dimensions of the appliance (HxWxD mm): 48 x 583 x 513
- Required niche size (HxWxD mm : 48 x 560 x (490 - 500)
- Minimum worktop thickness: 16 mm
- Total connected load: 7500 W
- Design: Built-in
- Controlelectronic
- Energy source: Electric
- Control positionfront
- Main surface material: Glass ceramic
- Color deviceblack
- Basic color of product: Not applicable
- Frame designframe
- Frame colorstainless steel
- Connected load: 7500 W
- Voltage: 220-240 V
- Frequency: 50; 60 TPU00040
- Plug typewithout plug (connection by electrician)
- Unit width: 58,3 cm
- Unit height4,8 cm
- Device depth: 51,3 cm
- Packed unit height10 cm
- Width of packed unit75 cm
- Depth packed product59 cm
- Minimum niche height49 cm
- Maximum niche height50 cm
- Minimum niche width56 cm
- Maximum niche width56 cm
- Niche depth4,8 cm
- Net weight: 7,8 kg
- Gross weight: 8,6 kg
- Energy consumption of the 1st heating element per kg188.8 Wh/kg
- Energy consumption of the 3rd heating element per kg186.7 Wh/kg
- Energy consumption of the 5th heating element per kg190.2 Wh/kg
- Energy consumption of the 7th heating element per kg190.0 Wh/kg
- Energy intelligent device, can optimize consumption behavior (2017/1369/EU): No
- Wireless communication possible: No
- Network broadband technology: Not applicable
- SIM card slot available: No
- Control interface typeno
- Possibility of remote upgrade: No
- Possibility of remote update for maintenanceno
- Automatic program: No
- Cooking zone position: front left
- Position of the 3rd cooking zone: rear left
- Position of 4th cooking zone: center rear
- Position of the 5th cooking zone: rear right
- Position of the 6th cooking zone: center right
- Position of the 7th cooking zone: front right
- Position of the 8th cooking zone: front center / central
- Position of the 9th cooking zone: central
- Type of cooking zone: radiant heating
- Type of 3rd cooking zone: radiant heating
- Type of 5th cooking zone: Radiant heating
- Type of 7th cooking zoneradiant heating
- Cooking zone dimensions18 cm
- Dimensions of the 3rd cooking zone: 26,5 cm
- Dimensions of the 5th cooking zone14,5 cm
- Dimensions of the 7th cooking zone21 cm
- Power of the 3rd cooking zone: 1.8 ; 2.6 W
- Power of the 5th cooking zone: 1.2 W
- Power of the 7th cooking zone: 1 ; 2.2 W
- Power indicator lightyes
- Cooking zone indicator light: 1 operation indicator light
- Control: Stepless energy control
- Cover type: Without
- Ignition: No
- Residual heat indicator: Separate
- Main switchyes
- Safety devices: Child safety lock, safety time out
- Electronic clock: No
- Possibility to combine cooking zones/areasno
- Time functionsno delay options
- Prevent boiling over with cooking sensorno
- Flexible induction technology supported no
- Hob with booster functionno
- Temperature control for perfect frying resultsno
- Cord includedno
- Wok burner supported: No
- COMBINED_NOMENCLATURE_CODE: 85166050
