Gaggenau RF411306, Series 400, Vario freezer, 212.5 x 45.1 cm, flat hinge with soft closing
- Stainless steel interior with solid aluminum elements in anthracite
- Glare-free LED spots with warm white light
- Opening aid for the door:
- 1. Push-to-open function for handleless furniture fronts 2. Pull-to-open function for easier opening of the door with handle
- The drawers of RC and RF are at the same height. With a side-by-side installation, shelves and door shelves can be aligned on the same levels
- Material and look of the interior as with RC
- - Door shelves made of solid anthracite aluminum - Shelves made of glass< /li>
- Stainless steel interior with solid aluminum elements in anthracite
- Glare-free LED spots with warm white light < li>Opening aid for the door:
- 1. Push-to-open function for handleless furniture fronts 2. Pull-to-open function for easier opening of the door with handle
- The drawers of RC and RF are at the same height. With a side-by-side installation, shelves and door shelves can be aligned on the same levels
- Material and look of the interior as with RC
- - Door shelves made of solid anthracite aluminum - Shelves made of glass< /li>
- Flat interior door with stainless steel, full surface
- Almost invisible and flexible suspension system for shelves and door racks
- Integrated ice maker with fixed connection for water supply
- TFT- Touch display
- Total usable content: 240 liters
- Operation via TFT touch display. < li>Plain text display.
- Dynamic cold distribution.
- Automatic defrosting with condensation water evaporation.
- Damped door closing system.
- Sleep mode, Star-K certified.
- When sleep mode is active, the door and drawer can only be opened with one handle.
- Alarm when the door is open or Malfunction.
- Remote control and monitoring.
- Remote diagnosis.
- Home network integration for digital services (Home Connect) wirelessly via WiFi.
- Use of the Home Connect function depends on the Home Connect services, which are not available in every country. Further information can be found at home-connect.com.
- No-frost technology with quick freezing at -30 °C.< /li>
- Temperature adjustable from -24 °C to -14 °C.
- 4-star freezer compartment.
- Freezing capacity 16 kg /24 hours. < li>Storage time in the event of a fault: 6 hours.
- 4 shelves made of safety glass, white glass, 3 of which can be individually adjusted in height.
- 2 fully extendable drawers with transparent fronts. < li>Brilliant LED spotlights with glare-free and warm white light (3500 K).
- Flat interior door with fully flexible suspension system for door racks.
- 4 height-adjustable door racks.
- Integrated into the freezer compartment, with fixed water connection (inlet).
- Particle filter for the water inlet, integrated into the ventilation grille.
- Saturation indicator in TFT touch display.
- Can be switched off.
- Ice production: approx. 1.4 kg/24 hours.
- Removable ice cube tray for a supply of approx. 4 kg.
- Energy efficiency class E on a scale of efficiency classes from A to G.
- Energy consumption 246 kWh/year.
- Noise value 42 dB (A) right 1 pW.
- Flat hinge.
- Door hinges on the left, changeable.
- Door opening angle 115°, can be fixed to 90°.
- If the device is installed with a door opening angle of 90°, the drawers can only be opened to a limited extent and the ice cube tray is against a small ice cube tray (RA 448 220). This must be done before fixing the door.
- Max. Permissible door front weight 59 kg.
- Shut-off valve for the water connection must be planned on the side of the device and always be accessible.
- If the water pressure is over 0.8 MPa (8 bar), pressure limiter between the drinking water connection and install hose set.
- Total connection value: 0.300 kW.
- Connection cable 3.0 m, pluggable.
- Water inlet.
- Inlet hose 2.0 m with 3/4 "connection.
- Water pressure range 2 to 8 bar.
- Product series: Series 400
- Product category: Freezer
- Design: Built-in
- Is this device a built-in device?: Yes
- Control: Electronic
- Product type : 1-door
- Type of installation: Fully integrable
- Control elements: Economy switch, holiday switch, super switch freezing, warning functions Freezer compartment, freeze warning signal, door open warning signal
- Basic color of the product: Not applicable
- Decorable: Not possible
- Connected load: 300 W
- Fuse: 10
- Voltage: 220- 240 V
- Minimum voltage: 220 V
- Maximum voltage: 240 V
- Frequency< /b>: 50-60 TPU00040
- Length of connection cable: 300.0 cm
- Plug type: Schuko/Gardy.m. Grounding
- Net capacity: 226 l
- Device height: 212.5 cm
- Device width : 45.1 cm
- Device depth: 60.8 cm
- Depth product with door open (90°) b>: 113.5 cm
- Door stop: Changeable on the left
- Height-adjustable feet: Yes - all < li>Height adjustment feet maximum: 7.9 cm
- Height of packed device: 227 cm
- Width of packed device : 55 cm
- Depth packed product: 74.5 cm
- Minimum niche height: 213.4 cm
- Maximum niche height: 213.4 cm
- Minimum niche width: 45.7 cm
- < b>Maximum niche width: 45.7 cm
- Niche depth: 61 cm
- Net weight: 132.8 kg
- Gross weight: 145.6 kg
- Type of defrosting technology (4-star compartment) (EU 2017/1369): Automatic
- Recommended temperature (4-star compartment) (EU 2017/1369): -18 °C
- Volume of the compartment (4-star compartment) (EU 2017/1369): 240.0 l
- Total of the volumes of the freezer compartments (EU 2017/1369): 240 l li>
- Total volume of the product (EU 2017/1369): 240 l
- Average energy consumption in kilowatt hours per year (kWh/a) (EU 2017/1369 ): 246 kWh/a
- Energy efficiency index (EU 2017/1369): 100
- “Quick freezing” function (EU 2017 /1369): Yes
- Freezing capacity (four-star compartment) (EU 2017/1369): 16.0 kg/24h
- < b>Type of light source (EU 2019/1805): LED
- List of compartments: 4 star
- Low-noise cooling device< /b>: No
- Maximum ambient temperature (EU 2017/1369): 43 °C
- Minimum ambient temperature (EU 2017/1369 ): 10 °C
- Airborne noise emissions (EU 2017/1369): 42 dB(A) re 1 pW
- Product excluded from the scope of application for "quiet device" and "wine storage cabinet" (EU 2017/1369): No
- QR code (EU 2017/1369): HTTPS: //EPREL.EC.EUROPA.EU/QR/743826
- Wine storage cabinet only: No
- “Winter switching” control function for combination device (EU 2017 /1369): No
- Energy-intelligent device, can optimize consumption behavior (2017/1369/EU): No
- Wireless communication possible: Yes, built into the device
- Lighting technology used (light source 1) (EU 2019/1805): LED
- Network -Broadband technology: Not applicable
- SIM card slot available: No
- Communication technology used: WiFi
- Type of interface for control: LAN
- Possibility for remote upgrade: No
- Possibility for remote update for maintenance: Yes
- Camera present in the device: No
- Included Accessories: 1 x ice cube scoop, 1 x connection set, 1 x ice container, small
- Door open freezer compartment indicator: No
- Fast freezing function: Yes
- Interior lighting: Yes
- Furniture door fastening: Permanently mounted
- Condensation drying : No
- Type of interior lighting: LED light
- Temperature adjustable: Yes
- Lockable door: No
- COMBINED_NOMENCLATURE_CODE: 84184020
| Energy efficiency class: | E |
| : | D |
| Product type: | freezers |
| Installation type: | Fully integrable |
| Device width: | 50cm |
| Controls: | Sparschaltung Urlaubsschaltung;Superschalter Gefrieren;Warnfunktionen Gefrierteil;Warnsignal Störung Gefrieren;Warnsignal Tür offenPer App;Taste |
| Shipping weight: | 146,00 kg |
| Item weight: | 132,00 kg |
| Dimensions ( Length × Width × Height ): | 60,80 × 45,10 × 212,50 cm |
