Bosch wkd28543, series 6, built-in washer-dryer, 7/4 kg
Performance and consumption
- Energy efficiency class washing and drying¹: E
- Energy efficiency class washing²: E
- Electricity consumption³ / water consumption4 washing and drying: 266 kWh / 68 liters
- Power consumption5 / water consumption6 washing: 77 kWh / 44 liters
- load Washing and drying / Washing: 1 - 4 kg / 1 - 7 kg
- Program runtime7 Washing and drying / Washing: 5:30 h:min /?2:50 h:min
- Spin efficiency class: b
- Spin speed**: 600 - 1355 rpm.
- Noise value: 72 db (a) re 1 pW
- Noise efficiency class: A
- Special programs: AllergyPlus/Hygiene, ExtraShort 15', Lint Rinse, Mix, Quick/Mix Quiet, Spin/Dry, Sportswear, Rinse/Spin, Delicates/Silk, Wool/Handwash
- Special programs Drying: Lint Rinse
- Buttons: Start, Speed selection, Change, Menu, Drying, Temperature and 24 h Ready in
- Fully electronic one-button operation for all wash and special programs
- Large display for program sequence, temperature, speed, remaining time and 24 h end time preselection, display of drying targets
- AutoDry function, time programs
- ActiveWater Plus: for the most efficient use of water even with small wash loads thanks to automatic load detection.
- Foam detection
- Unbalance control
- Signal at program end
- Child lock
- porthole with glass cover
- bull's eye stop left
- Magnetic lock for immediate door opening at the end of the program
- Metal locking hook
- AquaStop®: a bosch guarantee against water damage - for the life of the appliance*
- adjustable plinth height: 16.5 cm
- adjustable plinth depth: 6.5 cm
- Appliance dimensions (h x w x d): 82.0 cm x 59.5 cm x 58.4 cm
- Adjustable rear appliance feet from the front
- fully integrable
| Shipping weight: | 84,00 kg |
| Item weight: | 82,00 kg |
| Dimensions ( Length × Width × Height ): | 58,40 × 59,50 × 82,00 cm |
- Product seriesseries 6
- design: floor standing
- Controlelectronic
- Type of installation: Fully integrable
- controls: lcd, buttons
- Removable worktop: No
- Appliance type: front loader
- Door hinge: Left
- Color appliancewhite
- Base color of product: Not applicable
- Connected load: 2300 W
- Fuse protection: 10
- Voltage: 220-240 V
- Minimum voltage: 220 V
- Maximum voltage: 240 V
- Frequency50 TPU00040
- Minimum frequency: 50
- Maximum frequency: 50
- Connection cable length: 220.0 cm
- Plug type: Schuko/Gardy.w.grounding
- Height adjustable feetyes - all
- Unit height82 cm
- Appliance width: 59,5 cm
- Unit depth: 58,4 cm
- Product depth with door open (90°)96 cm
- Height packed unit87,5 cm
- width packed unit64,5 cm
- Depth packed product64,5 cm
- Net weight82,9 kg
- bull's eye: glass window
- Door / Double door: Not applicable
- gross weight: 84,8 kg
- Made to release silver ions (eu 2017/1369): No
- Energy consumption in kWh per kg per wash cycle in eco 40-60 program (eu 2017/1369): 0.774 kWh/kg
- Energy consumption in kWh per kg per wash and dry cycle in program eco 40-60 (eu 2017/1369): 2.662 kWh/kg/operating cycle
- Energy efficiency index in wash mode (eu 2017/1369): 89.8
- Energy efficiency index in wash and dry mode (eu 2017/1369): 81.9
- Max. Temperature in laundry during eco 40-60 program at half capacity (eu 2017/1369): 34 °C
- Max. Temperature in the laundry during the eco 40-60 program at a quarter of the capacity (eu 2017/1369): 30 °C
- Max. Temperature in the laundry during the eco 40-60 program at nominal capacity (eu 2017/1369): 42 °C
- Residual moisture in laundry during program eco 40-60 at half capacity in % (eu 2017/1369): 52 %
- Residual moisture of the laundry at program eco 40-60 at a quarter of the capacity in % (eu 2017/1369): 56 %
- Residual moisture of laundry at program eco 40-60 at nominal capacity in % (eu 2017/1369): 50 %
- Airborne sound emissions (eu 2017/1369): 72 db(a) re 1 pW
- Power consumption at time preselection (eu 2017/1369): 4.00 W
- Power consumption in networked standby mode (eu 2017/1369): 0.00 W
- Power consumption in standby mode (eu 2017/1369): 1.00 W
- Power consumption in off mode (eu 2017/1369): 0.50 W
- QR code (eu 2017/1369): HTTPS://EPREL.EC.EUROPA.EU/QR/1452058
- Maximum capacity in kg in wash mode (eu 2017/1369): 7.0 kg
- Maximum capacity in kg in wash and dry mode (eu 2017/1369)4,0 kg
- Rinsing efficiency in eco 40-60 wash program (eu 2017/1369)4.9 grams per kilogram
- Rinsing effect in wash and dry mode (eu 2017/1369)4.9 grams per kilogram
- Spin speed of eco 40-60 program at half capacity in rpm (eu 2017/1369)1400 rpm
- Spin speed of the eco 40-60 program at a quarter of the capacity in rpm (eu 2017/1369)1400 rpm
- Spin speed of program eco 40-60 at rated capacity in rpm (eu 2017/1369): 1400 rpm
- Washing efficiency index in eco 40-60 program (eu 2017/1369): 1.040
- Washing efficiency index in total wash and dry mode (eu 2017/1369): 1.040
- Wash cycle duration in eco 40-60 program in hours and minutes at half capacity (eu 2017/1369): 2:40
- Duration in wash cycle of eco 40-60 program in hours and minutes at a quarter of capacity (eu 2017/1369): 2:30
- Duration in wash mode of eco 40-60 program in hours and minutes at rated capacity (eu 2017/1369): 2:50
- Duration in full wash and dry mode in hours and minutes at half capacity (eu 2017/1369): 4:10
- Duration in full wash and dry operation in hours and minutes at rated capacity (eu 2017/1369) : 5:30: 5:30
- Water consumption in liters in eco program per operating cycle (eu 2017/1369)44 l/operating cycle
- Water consumption in liters in wash and dry mode per full cycle (eu 2017/1369)68 l/operating cycle
- Weighted energy consumption in kWh per 100 wash cycles in eco 40-60 program (eu 2017/1369): 77 kWh/100 operating cycles
- Weighted energy consumption in kWh per 100 complete wash and dry cycles (eu 2017/1369)266 kWh/100 operating cycles
- Energy smart appliance, can optimize consumption behavior (2017/1369/EU): No
- Wireless communication possibleno
- Network broadband technology: Not applicable
- SIM card slot availableno
- Control interface typeno
- Possibility of remote upgrade: No
- Possibility of remote update for maintenance: No
- Cold wash: Yes
- Remaining time displayyes
- Selectable languages in displaygerman
- Spin speed optionsvariable
- Automatic programyes
- Function without spinno
- Quantities detectionyes
- Other operation options: AllergyPlus / Hygiene, Extra Fast 15 min, Lint Rinse, Lint Rinse, Mix, Night Wash, Spin / Pump Down, Sport/Fitness, Rinse / Spin
- Water plusyes
- Dirt detectionno
- Foam detectionyes
- Unbalance controlyes
- Door opening typehandle
- Separate temperature selection possible: Step by step
- Program sequence displaylED display
- Material inner container: Plastic
- Drum volume: 52 l
- Drum material: stainless steel
- Start time preselection optionscontinuous
- Cold/hot water connection: No
- Stop delay or start delay option: Stop
- Max. Stop preset time: 24 h
- Humidity sensor: Autodry, by time selection
- Interior lighting: No
- Selectable drying temperature: No
- Reversing functionyes
- Control indicator "Clean filterno
- Steam functionno
- Type of water protection systemaquastop
- Software update: No
- Max. Temperature in the laundry during washing and drying at nominal capacity (eu 2017/1369): 34
- Max. Temperature in the laundry during washing and drying at half capacity (eu 2017/1369): 30
- Weighted average residual moisture of the laundry at program eco 40-60 in % (eu 2017/1369): 52.0
- COMbINED_NOMENCLATURE_CODE: 84501190
